Instrument 2 Way Ball Valve OD End
Brand:DE-LOK
Material:ASTM A 182 F316
Connection:Tube OD
Type:Ball Valve
Standard:Equal to Swagelok Standard
Features
Compact design
High flow rate with maximum orifice
Variety of end connections
Anti blow-out stem design
Each and every valves is tested at the factory
Specifications
Pressure Rating |
6000psig (414bar) @ 70℉(21℃) |
Temperature Rating |
-22 to 265℉(-30-130℃) with PVDF seat -65 to 500℉(-54-260℃) with PEEK seat |
Body Material |
316 Stainless Steel and Brass |
Port Connections |
1/4” to 1” and 6mm to 25mm |
Orifice |
10mm to 19mm |
Materials of Construction
No. |
Component |
Material Grade/ASTM Specification |
1 |
Body |
SS316/A182 |
2 |
End Connector |
SS316/A182 |
3 |
Ball |
SS316/A182 |
4 |
Seats |
PCTFE, optional PTFE, PEEK |
5 |
Retainer |
SS316/A182 |
6 |
Retainer Seal |
PTFE |
7 |
End Seals |
PTFE |
8 |
Stem |
SS316/A182 |
9 |
Stem Packing |
PTFE |
10 |
Stem Washer |
SS316 |
11 |
Packing Bolt |
SS316/A182 |
12 |
Lock Nut |
SS316/A182 |
13 |
Set Screw |
Stainless Steel |
14 |
Handle |
Bakelite |
Table of Dimensions
Order Number |
Orifice |
Cv |
End Connections |
Dimensions (mm) |
||||||||||
Series |
Part No. |
Inlet |
Outlet |
A |
B |
D |
E |
H |
C |
F |
d |
T |
||
DBL6M 01 |
1-1 |
1.3 |
0.06 |
1/6” DE-LOK |
33.0 |
33.0 |
8.5 |
10.0 |
23.2 |
18.0 |
47.0 |
16.3 |
3.3 |
|
2-2 |
2.4 |
0.21 |
1/8” DE-LOK |
34.5 |
34.5 |
|||||||||
2N-2N |
4.2 |
0.93 |
1/8” Female NPT |
27.2 |
27.2 |
|||||||||
2MN |
1/8” Male NPT |
29.9 |
29.9 |
|||||||||||
4-4 |
1/4” DE-LOK |
37.6 |
37.6 |
|||||||||||
4MN |
1/4” Male NPT |
34.3 |
34.3 |
|||||||||||
3M-3M |
2.2 |
0.18 |
3mm DE-LOK |
34.8 |
34.8 |
|||||||||
DBL6M 02 |
2-2 |
2.4 |
0.26 |
1/8” DE-LOK |
41.9 |
41.9 |
11.9 |
10.7 |
38.9 |
30.0 |
78.0 |
19.6 |
6.4 |
|
4-4 |
4.8 |
1.04 |
1/4” DE-LOK |
44.2 |
44.2 |
|||||||||
4-4MN |
1/4” Male NPT |
1/4” DE-LOK |
41.1 |
|||||||||||
4-4N |
1/4” Female NPT |
1/4” DE-LOK |
38.4 |
|||||||||||
4N-4N |
6.4 |
2.34 |
1/4” Female NPT |
38.4 |
38.4 |
|||||||||
4MN |
1/4” Male NPT |
41.1 |
41.1 |
|||||||||||
4N-4MN |
1/4” Male NPT |
1/4” Female NPT |
38.4 |
|||||||||||
6-4MN |
1/4” Male NPT |
3/8” DE-LOK |
45.7 |
|||||||||||
6-4N |
1/4” Female NPT |
3/8” DE-LOK |
38.4 |
|||||||||||
6-6 |
3/8” DE-LOK |
45.7 |
||||||||||||
6MN |
3/8” Male NPT |
41.1 |
41.1 |
|||||||||||
6M-6M |
4.8 |
1.04 |
6mm DE-LOK |
44.5 |
44.5 |
|||||||||
8M-8M |
6.4 |
2.34 |
8mm DE-LOK |
45.2 |
45.2 |
|||||||||
10M-10M |
10mm DE-LOK |
46.0 |
46.0 |
|||||||||||
DBL6M 03 |
6N-6N |
10.3 |
6.42 |
3/8” Female NPT |
49.5 |
49.5 |
17.8 |
17.5 |
44.2 |
38.1 |
99.0 |
22.9 |
9.7 |
|
8N-8N |
1/2” Female NPT |
54.6 |
54.6 |
|||||||||||
8-8 |
1/2” DE-LOK |
59.4 |
59.4 |
|||||||||||
8MN |
1/2” Male NPT |
56.4 |
56.4 |
|||||||||||
12-12 |
3/4” DE-LOK |
59.2 |
59.2 |
|||||||||||
12M-12M |
9.5 |
5.57 |
12mm DE-LOK |
|||||||||||
16M-16M |
10.3 |
6.42 |
16mm DE-LOK |
